2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204
  • 2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204
  • 2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204
  • 2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204
  • 2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204
  • 2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204

2 x UTP 4 Channel Passive Video Balun Transceive BNC to RJ45 CCTV Adapter X204

$12.45



  • Description
  • Reviews
  • Shipping & Returns

Feature:

  • (4 channel passive video balun)
  • Full-motion CCTV video at distances up to 330m when used with any passive transceiver
  • Up to 1500m with any active UTP video receiver
  • 60 dB crosstalk and noise immunity
  • NTSC, PAL , and SECAM video formats
  • No power required
  • Built-in transient suppression protection

Specification:

  • Frequency response: DC-8MHZ
  • CMRR (Common Mode Rejection Ratio):60DB
  • Impedance BNC: 75O ; RJ45:100O
  • Working temperature: -10°C-70°C
  • Storage temperature: -30°C-70°C
  • Humidity: 0 to 95%
  • Applicable to NTSC, PAL, SECAM and CCIR systems
  • External dimension: 75mm*50mm*25mm (excluding BNC)
  • Connectors: Male BNC and Rj45
  • Surge suppression: 6000V 1.2 uS x 50 uS
  • weight: 92g
  • Type of the required wire: Unshielded Cat-5 or above twisted pair wire (Please use standard Cat-5 or above twisted pair wire. The wire quality will directly affect the transmitted image effect and transmission distance.)
  • Characteristic impedance: 100O+-20O
  • DC loop resistance: 18O/100m
  • Differential capacitance: 62pf/m (Maximum)

Packing including:

  • 2 x UTP 4 Ch Passive Video Balun Transceive BNC video balun to UTP RJ45
