M4070 Electric Meter With AutoRanging LCR Capacitanc Meter Up to 100H 100mF 20MR

$69.95



  • Description
  • Reviews
  • Shipping & Returns

Description:

  • M4070 LCR meter is auto-ranging component tester, can drive up to 500 KHz, suitable for small value capacitor and inductor measurement. It provides very stable and high resolution measurement up to 5 digits. Meter can measure 0.00pF to 100.00mF capacitance, 0.000uH to 100.00H and 0.00Ohm to 10.000MOhmThis meter is using two technique measurement, LC oscillation and RC oscillation. LC is much suitable for small value measurement and RC for high value capacitance.

Features:

  • Fully auto-ranging designed
  • High resolution, up to 5 digit display, most finest resolution: 0.01pF, 0.001uH, 0.01R
  • High stability and measurement range for L/ C/ R
  • USB charging with rechargeable battery inside
  • Large LCD display with backlight
  • USB PC program, can take record and pass and fail component sorting function.

Specification:

  • Model:

    M4070

    LCR Meter Series

    LCR Testing Parameter

    Main Parameter: L / C / R

    Testing frequency



    C: 10 to 500Khz



    L: 10 to 360Khz

    Testing Method



    Auto select LC and RC Oscillation

    Calibration



    Power on auto calibrate with internal reference capacitor

    Testing voltage

    ~1.5Vrms

    Best Tolerance

    L: 1% +1 Digit



    C: 1% +1 Digit



    R: 0.5% +1 Digit

    LCD update or Testing time (* vary on component value)

    <3/s, (e.g. 100mF Capacitor <30s)

    Range Selection

    Automatically



    Zeroing

    Open / short circuit



    Terminal

    Mini-USB(Virtual Com Port)

    Display Range

    C

    0.00pF~100.000mF (pF/nF/uF/mF)

    L

    0.000uH~ 100.000H (uH/mH/H)

    Hz (LC Oscillation Frequency)

    0 to 900000Hz

    (s) (RC Constant Time)

    0.000 to 99.999

    R

    0.00 Ohm ~ 20.000 MOhm (Ohm/kOhm)



    LCD Display

    128X64 Dot Matrix, with backlight

    Fuse Protection



    200mA

    Charging terminal



    Mini-USB (500mA)

    Battery



    internal 3.7V Li-polymer

    Number of Testing Terminal

    Main 3, Secondary 4

    Reading Display

    Max. 99999


Packing including:

  • 1 x M4070
    1 x USB Cable
    1 Pair Test Probe
    1 Pair SMD Clip Probe
