4K Ultra HD 30fps SONY imx334 1/1.8" Sensor HDMI port USB output WIFI digital microscope camera 4K HDMI USB microscope camera + 40X-400X Parallel Light Microscope Camera Manual Zoom C-mount Lens

$680.00



  • Description
  • Reviews
  • Shipping & Returns

4K Ultra HD 30fps SONY imx334 1/1.8" Sensor HDMI port USB output WIFI digital microscope camera 4K HDMI USB microscope camera
+ 40X-400X-800X-1250X Parallel Light Microscope Camera Manual Zoom C-mount Lens






The XCAMLITE4K series is the next-generation live-view imaging-system with 4K resolution at 30 FPS.

XCAMLITE4K series comes with Sony Exmor CMOS sensor with high sensitivity, low dark current and no smear achieved through the adoption of R, G and B primary color mosaic filters.

The camera uses a standard C-mount interface for maximum compatibility with various microscopy-systems. It can be used as a stand-alone recorder when used with an HDMI monitor or television, or live-streamed to a PC via USB for image-capture and video-recording.

Hardware 3D denoising, sharpness and local tone mapping control functions greatly improve the image and video quality.



The included Windows software offers image-development and measurement tools, as well as advanced compositing features such as image-stitching and extended-depth-of-focus. With the ability to calibrate scales at multiple magnifications, the software can be used for multi-level inspection. For Mac and Linux, there is a lite version of the software which can capture video and still images, and includes limited processing features.
















Camera Application:



  • Scientific research, digital teaching (teaching, demonstration and academic discussing);
  • Digital laboratory, medical research;
  • Machine vision (PCB detection, IC quality control);
  • Medical treatment (pathological observation);
  • Food (microbial colony observation and counting);
  • Aviation and military;



Feature:



  • 4K HDMI multiple video output
  • Double Cortes ARM 53 CPU processor, high performance and fast response video
  • H.265/H.264 codec
  • 8G bit DDR4 running smoothly
  • 4k/1080P switch adaptively, Preview frame rate 30fps, max recording frame rate: 30fps
  • 20fps for USB port output
  • Embedded measurement functionsand meausurement objects can be exported to Excel or saved with the image data in layer mode or in burn in mode.
  • RisingView application for the PC output via USB3.0 port

Specification:



  • Sensor(option): SONY imx334 Sensor, senzor size:1/1.8"
  • Pixel(μm) : 2.0x2.0 (SONY imx334)
  • Resolution: 4K Ultra HD (8mp 3840x2160)
  • Preview frame rate: 30fps @ 4K under HDMI , 20fps@3840x2160 (USB)
  • Max recording frame rate: 30fps under HDMI
  • Exposure : 0.1ms~1000ms
  • Real time measurement
  • Support U disk and SD card storage
  • HDMI, USB output







Video Output:



  • HDMI Interface
  • 1. Comply with HDMI2.0 standard;
  • 2. Max frame rate 30fps@4K or 30fps@1080P;
  • 3. The video saved into SD card or USB drive, video can be replayed on TV monitor directly from SD card or USB drive
  • USB3.0 Output
  • 1. Max frame rate 20fps@4K Resolution
  • 2. Camera Working with Computer via USB3.0 cable,
  • 3. RisingTech will provide RisingView software for buyer



Spectral Range   380-650nm (with IR-filter)



Other Specification for HDMI Output

UI Operation With USB Mouse
Image Capture 8M (3840*2160) JPEG Image in SD Card or USB Flash Disk
Video Record Video Format:8M(3840*2160) H264 Encoded MP4 Format
Video Recording Frame Rate:30FPS(related with the SD card speed class and video resolution)
Camera Control Panel Including Exposure, Gain, White Balance, Color Adjustment, Sharpness and Denoising Control
Toolbar Including Zoom, Mirror, Comparison, Freeze,

Cross, Browser Function

Other Specification for USB Output

Resolution

White Balance

8M (3840*2160)  frame rate 30fps

Auto/Manual/ROI White Balance

Color Technique Ultra-Fine Color Engine (USB)
Capture/Control API Standard network API for Windows/Linux/Mac(USB)
Recording System

Still Picture or Video





Operating Environment
Operating Temperature(in Centidegree) -10~ 50
Storage Temperature(in Centidegree) -20~ 60
Operating Humidity 30~80%RH
Storage Humidity 10~60%RH
Power Supply DC 12V/2A Adaptor





Camera Control Panel:





Camera Measurement Toolbar:





  • The Measurement Toolbar will pop up when moving mouse cursor to any place near the upper edge of the video window. Here is the introduction of the various functions on the Measurement Toolbar








Zoom C-mount Lens:






  • Manual Zoom C-mount Parallel light Lens
  • Standard objective lens is 1X
  • Aux Objective lens:  1X
  • Zoom ratios: 6.5 : 1
  • Standard Objective Magnification Power by 0.7 - 4.5X
  • Optical multiplication: 0.7X -4.5X
  • About 40 - 400X on the 21 inch LCD display (by 1/3 inch CDD)
  • Visual field: 1mm-8mm
  • Working distance: W.D.100mm, holder diameter: Φ40mm / Φ50mm,
  • Focus Fine: any position focus of C/CS Mount
  • Iris Adj:high definition and high depth of focus
  • Large depth of field



Package including:



  • 1 x 4K Camera (SONY imx334 Sensor)
  • 1 x HDMI cable
  • 1 x USB3.0 Cable (USB Video Cable)
  • 1 x Mouse
  • 1 x WiFi transmitter
  • 1 x Power Supplier (EU, US and UK for choice)
  • 1 x 96LED Ring light
  • 1 x Metal Microscope Stand
  • 1 x Zoom C-mount Lens
