- 2019 Latest industrial camera
- High Quality, High Resolution, Clear Images
- 38.0MP 1/3 Inch big size Japan CMOS
- TF Card Video Recorder
- Photo Model / Video Model
- Industry Cmos Camera. It can Show the live image directly on any HDMI monitor , Projector or TV.
- It build in digital crosshairs and color control, add line in the pictures, freeze ,Mirror, Rotate, Negative
- Supply USB2.0,HDMI HD video,Two output ports
- We sell much to the industy factory, then the works can see the problems directly in the Monitor.
- Sensor: 38 MegaPixel CMOS
- Optical format:1/3inch
- Interface:HDMI(Type A).USB(Type B).TF Card
- Image resolution:38MegaPixel
- Video record resolution:2K@24FPS 1080p@60FPS
- HDMI resoltion:2K@24FPS 1080p@60FPS
- HDMI scale:Support 4:3,16:9 screen
- USB2.0(Drive free):1920*1080@30FPS 1280*720@30FPS 640*480@30FPS
- TF card:MAX 64GB
- AWB:WB color correction/Auto/Manual
- R.G.B value setting independent
- Exposure:Auto/Manual.AE value can set
- Cross lines:8lines.Can set color& width& position
- Scale mark lines:2lines.
- Sharpness Contrast Color gain:Support
- Mono Negative:Support
- Mirror:Horizontal vertical mirror
- Language:English/simplified Chinese
- Digital Zoom:Support
- IR remoter:Support
- Lens interface:C/CS Mount
- Working distance: 95mm
- zoom c-mount Lens
- 0.5X C-mount adapter
- zoom ratios: 6.5:1
- Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)
- Size: 180mm(L) * 50mm(DIA)
- Weight: 450g
- 144 bright white LED bulbs
- 100,000 hours of life
- Intense and focused shadow-free illumination
- The brightness of 0-100%Adjustable,high brightness
- Variable intensity control
- Power input: 100-240V, 50-60HZ
- Suit for the dia of the lens: 30mm-63mm
- This stand has a dual arm system with a counterweight on the opposite end of arm to counter the weight of your microscope head. This gives more stability compared with a common type of boom stand.
- The multi-axis rotation feature allows this boom stand to locate your microscope head to most any position or angle. This can be a greatly needed tool when you have a hard-to-see location such as inspecting and searching for cracks on the solder of a circuit board.
- Easy Large-Sized Focusing Knobs on Both Sides of Focusing Holder.
- Steel Gears on Focusing Holder.
- Standard Size Focusing Holder - Will Fit Scope Heads with Diameter of 50mm
- Weight: 3.3kg
- 1 x 38.0MP Industrial Digital Camera
- 1 x Power Supply
- 1 x HDMI Cable
- 1 x 10X-180X C mount Lens
- 1 x 0.5X AUX Lens
- 1 x 2X AUX Lens
- 1 x Universal Stand
- 1 x 144 Bulbs Microscope LED Ring Light
